BIG ANNOUNCEMENT: 5 Year Full Warranty on Our All New Fiber Laser Machines – Parts, Labour, Source, Head & UK Support!

FABERTEC FL2

1325 / 1530 / 2030 / 2040

AFFORDABLE FIBER LASER CNC CUTTING MACHINE WITHIN REACH OF EVERY WORKSHOP SMALL OR LARGE

The FABERTEC FL2 is an entry-level fiber laser cutter designed specifically for smaller metalwork workshops aiming to enhance their operations and reduce subcontracting costs. With a laser power starting from 1kW up to 6kW, this machine is capable of cutting mild steel with thicknesses ranging from 0.1mm to 25mm. One of the key advantages of the FABERTEC FL2 cnc fibre laser is its affordability, making it an ideal choice for workshops and fabricators with budget constraints. By investing in this model, smaller businesses can improve their cutting capabilities while saving costs associated with outsourcing to subcontractors.

The fiber laser machine is available in four standard table sizes: 1300 x 2500mm, 1500 x 3000mm, 2000 x 3000mm, and 2000 x 4000mm. Those table sizes provide flexibility to accommodate various project requirements. Additionally, bespoke table sizes can be customized to meet specific needs upon request, ensuring a perfect fit for any workspace. All FABERTEC fiber laser cutters are equipped with high-speed and powerful servo motors. These motors enable the machine to achieve impressive cutting speeds of up to 60 meters per minute. This feature significantly contributes to efficient cutting operations, allowing for faster production and improved productivity shifts.

fiber laser machine in uk
fiber laser machine in uk

FL2 - RAPID LEARNING AND USEABLE BY EVERYONE

Our main focus was on allowing almost anyone to start to use machine safely in matter of minutes. The CAD/CAM software installed with every FL2 is capable of drawing your own shapes and cutting from the same level. The program can be easily learned and operated, enabling operators to quickly cut metal sheets just after 30-60min of training.

At FABERTEC, we prioritize user-friendliness in our machine design, ensuring that even apprentices in the workshop can operate our machines with minimal training. This capability not only saves on employee costs but also enables workshops to start CNC cutting immediately upon receiving the machine without hiring an experienced and in most cases costly new operator.

NOTE

  • 1) Please be aware that it is a Class 4 Laser product, so you need to position open bed fiber laser machine in an enclosed area where no one except the operator can be exposed to the laser light. Operators need to wear protective glasses at all times (supplied).
  • 2) Single phase (230v) up to 2kw laser source.

LASER SOURCE - THE HEART OF FIBER LASER CUTTING MACHINES

In all fiber laser cutting machines, the laser source is one of the most important parts that allows for smooth and accurate cuts. At FABERTEC we offer reliable and affordable MAX/RAYCUS laser sources.

Before 2024, we considered IPG as the go-to laser source, but after gaining in-depth training in laser source repairs and opening the first UK repair center,        FABERTEC PHOTONICS, we’ve come to value MAX/RAYCUS brands with much more respect.

MAX/RAYCUS sources offer the same cutting quality, speed, and accuracy as higher-priced alternatives but at around 30–40% of the cost. What’s most important in our opinion is the fact that these affordable brands can be repaired with ease, spare parts are readily available, and they’re designed to be more open for local service centres. Of course, the final choice depends on your budget and preferences. At FABERTEC, we supply and install MAX or RAYCUS sources from our UK branch with full support.

⚠️ When cutting reflective materials like brass or copper, you must ensure the material is properly pierced to prevent bounce-back light from returning to the laser source. Damage caused by such reflections may not be covered by the manufacturer.

fabertec max-raycus photonics laser source

FL2 - TRANSPARENCY, AFFORDABILITY, AND QUALITY

For over 20-30 years since mass produced fiber lasers appeared in metal fabricators workshops the entry price for those machines was insanely high as it happens with all new technologies. Just 10 years ago the 1kW entry model from TRUMPF, AMADA or BYSTRONIC would set you back £200-300k. As the technology moved forward and lots of firms started to invest in fiber source manufacturing facilities the cost of parts starts to drop quite significantly even to a point where metal fabricator can start with rapid metal cutting FABERTEC FL2 1kW for only £32k+VAT.

As we are also fabricators we don't have time for long quotations, endless emails and small prints in pricing. We always will advertise clearly all of our prices without any hidden costs. What you see is what you pay - no extras for software, consumables, delivery, commissioning, training and ongoing support.

CLARITY IN PROCUREMENT IS VERY IMPORTANT TO US

fiber laser machine in uk

Affordable prices to allow you to speed up your workshop processes.

max laser  1kw  2kw  3kw  4kw  6kw
FABERTEC FL2 1325  £32,000  £36,000  £42,000  £50,000  £58,000
FABERTEC FL2 1530  £36,000  £40,000  £46,000  £54,000  £62,000
FABERTEC FL2 2030  £40,000  £44,000  £50,000  £58,000  £66,000
FABERTEC FL2 2040  £46,000  £50,000  £56,000  £64,000  £70,000
ipg laser  1kw  2kw  3kw  4kw  6kw
FABERTEC FL2 1325 £40,000 £45,000 £50,000 £68,000 £84,000
FABERTEC FL2 1530 £44,000 £49,000 £54,000 £72,000 £88,000
FABERTEC FL2 2030 £52,000 £57,000 £62,000 £80,000 £96,000
FABERTEC FL2 2040 £56,000 £61,000 £66,000 £84,000 £100,000

Lease Purchase

MODEL  TOTAL PRICE MONTHLY    WEEKLY  DAILY
 FL2 1325 1kW Max Source   £32,000  £720 £166  £24
 FL2 1530 1kW IPG Laser  £44,000  £990  £229  £33
fiber laser full spare parts
fiber laser water chiller and ipg laser source

Have you ever wondered why Fabertec fiber laser machines are so affordable? Here's why:

Why Fabertec Fiber Lasers are so affordable?

Delivery

We provide free of charge delivery of the FL4 machine. On the Client side you will need forklift 5t-7t with 2000-2400mm forks (dependable on model) to unload and position in workshop.

After delivery, our engineers will visit the workshop to complete installation, commissioning, and training. This visit will be scheduled separately, based on the client’s availability and the engineer’s schedule.

Don't worry if on first day you may not be very fluent with all operations (most operators cut on their machines in about 1h). We will provide you with our WhatsApp number where engineers will help if stuck or doubt.

Warranty

  • 5 Year Full Warranty (Parts, Labour, Source, Head & UK Support) included - for all new Fiber Laser Machines supplied from 1st June 2025 onwards.
  • Obligatory maintenance visits every 12 months to keep your machine in top condition £1,500 + travel time (£85/h) + Fuel surcharge (£0.90/m)
  • Machines supplied earlier continue under their original terms and conditions.

What is Included in the Package?

Fully assembled machine ready for work from our UK based workshops, all consumables like nozzles, lenses. Laser source and matching chillers. Demineralised water to fill your chiller on installation day. Lifetime software to draw and operate machine. Delivery on hiab, Installation and training. WhatsApp support to help operators with any issues.

LASER HEAD - THE "FOCUS" OF THE MACHINE

raytools bm06k 0 to 6kw auto focus laser head
raytools bm06k 0 to 6kw auto focus laser head

Features of Laser Head BM06k 1kW to 6kW Power

  • The cooling structure, for both the collimation module and focus module, and cooling to the nozzle effectively protects the nozzle & ceramic part and extends the lifespan.
  • 4 cover glass designed to effectively decrease contamination risk during the replacement of fiber & cover glass and extend the lifespan of collimation and focus lenses.
  • Autofocus by moving the collimation lens to achieve higher speed and a bigger auto-focus range.
  • Monitoring the temperature of the bottom cover glass could be accessed by a mobile APP or computer desktop in real-time. Alarm output for overheating to protect the optical path system effectively.
  • Improved autofocus motor for rapid focus length change.
  • The body of the laser head is designed in such a way to maximize the coolant liquid flow to prevent damage to collimating and focusing modules and ceramic nozzle.
  • By adding 4 protective lenses the Raytools BM06K laser head minimizes the risk of contaminating crucial and expensive to replace components.
  • Integrated temperature sensors close to the lower protective lenses monitor the optimal condition for efficient cutting.
  • Improved design of the fiber interface ( QBH, QD, G5) provides a tight, sealed connection preventing dust ingress.
  • Integrated design to ensure sealing.Improved fiber interface (QBH, QD, G5) to benefit their compatibility with lasers and prevent them from being stuck for leaks and rusts.

Features of Laser Head BLT 421 1kW to 8kW Power

BLT 4 Bochu Fiber Laser cutter Head
Fiber Laser cutter Head
BLT421 Fiber Laser Cutter Head Protective screws

Dust Protection by Design

Multiple protective lenses easily accessible to replace. Focusing and Collimating lenses accessible without the need to disassemble the laser head

Stable and Efficient Cutting

Brand new optical solutions come with closed-loop auto focusing. Slag-free Cutting, Nozzle Cooling, and Water Cooling Sensor supported.

Collision Screws

Using specially designed screws with shock-absorbent properties can minimize the risk of damage to your laser head during collisions.

Fiber Laser FL2 Dimensions

fabertec-fl2-13225-control-box-chiller-and-ipg-source
FABERTEC FL2 1325 FIBER LASER DIMENSION
FABERTEC FIBER LASER FL2 1530 DIMENSION
FABERTEC FL2 2040 FIBER LASER DIMENSION

Fiber Laser Cutting Specification

Responsive Notification Boxes
Will Cut
Will Cut with Altered Settings/Dross May Be Present
Will Not Cut



Material MAX 0.5mm 1mm 1.5mm 2mm 3mm 4mm 5mm 6mm 8mm
MILD STEEL 1kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 1kW ✔ ✔ ✔ ✔ ✔ ✔ ✘
STAINLESS STEEL 1kW ✔ ✔ ✔ ✔ ✔ ✘
BRASS 1kW ✔ ✔ ✔ ✔ ✘
COPPER 1kW ✔ ✔ ✔ ✘
Material MAX 0.5mm 1mm 1.5mm 2mm 3mm 4mm 5mm 6mm 8mm 10mm 12mm 14mm
MILD STEEL 2kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 2kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
STAINLESS STEEL 2kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
BRASS 2kW ✔ ✔ ✔ ✔ ✘
COPPER 2kW ✔ ✔ ✔ ✘
Material MAX 0.5mm 1mm 1.5mm 2mm 3mm 4mm 5mm 6mm 8mm 10mm 12mm 14mm 16mm 18mm 20mm
MILD STEEL 3kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 3kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
STAINLESS STEEL 3kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
BRASS 3kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
COPPER 3kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
Material MAX 0.5mm - 5mm 6mm 8mm 10mm 12mm 14mm 16mm 18mm 20mm 22mm 24mm 26mm
MILD STEEL 4kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 4kW ✔ ✔ ✔ ✔ ✔ ✔ ✘
STAINLESS STEEL 4kW ✔ ✔ ✔ ✔ ✔ ✘
BRASS 4kW ✔ ✔ ✔ ✘
COPPER 4kW ✔ ✔ ✘
Material MAX 0.5mm - 6mm 8mm 10mm 12mm 14mm 16mm 18mm 20mm 22mm 24mm 26mm 28mm 30mm
MILD STEEL 6kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 6kW ✔ ✔ ✔ ✔ ✔ ✔ ✔
STAINLESS STEEL 6kW ✔ ✔ ✔ ✔ ✔ ✘
BRASS 6kW ✔ ✔ ✔ ✔
COPPER 6kW ✔ ✔ ✘
Material MAX 0.5mm - 10mm 12mm 14mm 16mm 18mm 20mm 22mm 24mm 26mm 28mm 30mm 32mm 34mm 36mm
MILD STEEL 8kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 8kW ✔ ✔ ✔ ✔ ✔ ✔ ✘
STAINLESS STEEL 8kW ✔ ✔ ✔ ✔ ✔ ✘
BRASS 8kW ✔ ✔ ✔ ✘
COPPER 8kW ✔ ✔ ✘
Material MAX 0.5mm - 14mm 16mm 18mm 20mm 22mm 24mm 26mm 28mm 30mm 38mm 40mm 42mm
MILD STEEL 12kW ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✘
ALUMINIUM 12kW ✔ ✔ ✔ ✔ ✔ ✘ ✘
STAINLESS STEEL 12kW ✔ ✔ ✔ ✔ ✔ ✘
BRASS 12kW ✔ ✔ ✔ ✘
COPPER 12kW ✔ ✔ ✘

Please note: This document provides a general overview of the cutting parameters achievable with the MAX Laser Source. Areas marked in red represent "peak" performance for specific thicknesses. If your primary cutting requirements fall within the red range, it is advisable to consider upgrading your kilowattage to achieve improved performance and feed rates.

See our video demonstrations below:

Fabertec Fiber Laser FL4 12kW Precision Cutting & Engraving 5mm Stainless Steel

Cutting Samples

CUTTING-SAMPLES-OF-FIBER-LASER
FIBER LASER CUTTING SAMPLES
Fiber Laser Cutting Samples
FIBER-LASER-CUTTING-SAMPLES

Some of the important features of the Fabertec FL2 Fiber Laser

By using branded servo motors from Fuji or Yaskawa our fiber lasers can achieve speeds of up to 80m/min.

You have choice of IPG German/US brand or MAX/RAYCUS Laser source. We stock a lot of them in UK branch.

All of our FL2 machines have integrated controller and laser head which can be upgraded in no time from 1kW – 6kW. Thicker sheets in a year time? Just invest in more powerful laser source.

We are based in Lincolnshire and Fabertec being British brand we understand that you need to have your machine operational in no time in case of breakdown. Our engineers will always be on hand to help you out.
For rapid movements and direction changes. The lighter the gantry the quicker your fiber laser will work. Also less stress on structural rails and guides.
The FL2 features a smart compact electrical cabinet, even for the smallest of workshops, the wheels provide easy movability.
The FL2 offers a large screen display, not only does it look the part this comes in handy when nesting parts, adjusting vectors or even drawing new ones - all from one easy to use software.
Easy to replace bed slats. Just cut your own from 3mm mild steel and replace if old ones are no good anymore.
The FL2 has a 3 way solenoid valve to ensure smooth and fast gas changes. Just click in software what gas you want to use and controller will take care of the rest.
The FL2 features its own cad/cam package this allows you to draw and nest parts without flicking through different programs. What's most important it's so easy to use that even 15 year old apprentice will be cutting after 30min training.
Strong and durable linear guides with powerful servo motors allows FL2 to move rapidly and quite fast. That's very important when you investing in more KW source and cutting thin sheets where gantry can travel even at 40-50m/min
Move, set, specify datum point, switch on laser, red dot, start, pause, stop etc - all at your finger point.
The FL2 has a great loading facility at the front of the machine, the steel ball bearings allow for heavy sheets of material to be loaded with ease.
The scrap trays on the FL2 are perfect for easy access and emptying, they slide with ease even when they are full.

Are you looking for a fully enclosed double table fiber laser cutter?

Please consider Fabertec FL4 Fiber Laser Cutter



Technical specification

  • Max/Raycus or German IPG laser source – advertised manufacturers fiber laser lifespan up to 100,000 hours – equivalent of 10h daily cutting for 27 years!
  • Structure fully welded and heat destressed
  • Full servo motors Fuji or Yaskawa installed
  • Speeds up to 80 meters per minute
  • Aluminium reinforced gantry for higher speeds
  • Hiwin runners with automatic lubrication
  • Digital touch height control – laser head follows sheet height on the table (DTHC)
  • Automatic height adjustment – laser heads follows sheet height on the table
  • Automatic calibration – the controller automatically checks the laser settings
  • Large monitor with Cypcut software
  • Handheld wireless control panel
  • Draw, adjust, import DXF/PDF, create lead in/out – all straight from the machine
  • Two separate inlets for oxygen/nitrogen controlled by electric valves
  • Automatic focus of laser head from software
  • Supplied with array of nozzles, protective lenses, spares
  • Runners and linear gear protection against ​laser and sparks possible damage
  • Drawers underneath the table for offcuts/parts
  • Supplied with powerful chiller also with the heating option – in case workshop temperature goes below 0 to prevent damage from water freezing
  • Optional dust extractors with fire protection to keep the warehouse free from metal dust
  • Single phase (230v) up to 2kw laser source
