Clean, High-Pressure Air for Fiber Laser Cutting
LaserPro is designed for fiber laser machines that require precision air cutting. With 16 bar high-pressure delivery and 5-stage filtration, it ensures ISO Class 0 purity- reducing nozzle wear, protecting optics, and achieving burr-free cuts on even thick metals.
Built specifically for 3 kW to 6 kW fiber lasers, it provides the stable, ultra-dry air needed for fast, clean cuts in stainless steel, mild steel, and aluminium. LaserPro also helps extend the life of your laser head and consumables by maintaining consistent pressure and purity with every cut.
Technical Specification
| MODEL SPECIFICATIONS | RH-15kW | RH-20kW |
|---|---|---|
| Motor Power | 11kW | 15kW |
| CFM / Capacity / Pressure (m³/min / MPa) |
60CFM – 1.7 / 0.8 | 79.5CFM – 2.25 / 0.8 |
| 53CFM – 1.5 / 1.0 | 67CFM – 1.9 / 1.0 | |
| – | 38.9CFM – 1.1 / 1.6 | |
| Tank (L) | 400L | 400L |
| Length (mm) | 1800mm | 1800mm |
| Width (mm) | 800mm | 800mm |
| Height (mm) | 1630mm | 1630mm |
| Net Weight (kg) | 550kg | 550kg |
Technical Highlights
| MODEL | POWER | PRESSURE | FILTRATION | TYPICAL USE CASE |
|---|---|---|---|---|
| LaserPro 15 | 15kW | 16 bar | 5-stage | 2–3 kW laser cutting, clean air cutting |
| LaserPro 20 | 20kW | 16 bar | 5-stage | 3–6 kW thick sheet metal cutting |
All LaserPro models include:
Refrigerated air dryer + coalescing, particulate, and carbon filters, Condensate separator & auto drain, Class 0 oil-free air output, Intelligent control panel, Vibration-isolated mounting, 5 stage filtration to provide air as close to 99% cleanliness as possible.
Key Features
- Delivers 16 bar air pressure consistently
- 5-stage filtration ensures ISO 8573-1 Class 0 purity
- Supports 3 kW – 6 kW fiber lasers
- Ideal for cutting stainless steel, mild steel & aluminium
- Protects laser optics and extends consumable life
- Available in: 15 kW, 20 kW
When it comes to high-performance fiber laser cutting, every detail matters, and that starts with clean, pressurised air. LaserPro is built to deliver just that, ensuring precision, protection, and consistency for every cut. If you're serious about laser quality, LaserPro is the compressor built for you.
